ProtoGrid is a parametric generator for prototype perfboards.
Configure your grid, add power rails, mounting holes and silkscreen labels –
then export production-ready Gerber files for PCB manufacturers like JLCPCB or PCBWay.
Everything you need to go from idea to manufactured perfboard.
📐
Parametric Grid
Set board dimensions, pad pitch and grid size. The layout adapts instantly to your requirements.
⚡
Power Rails
Add configurable VCC and GND rails along the edges of your board – just like a classic breadboard.
🔩
Mounting Holes
Choose from diagonal or corner mounting hole patterns with configurable drill diameters and edge distances.
🔤
Silkscreen Labels
Row numbers and column letters printed on the board for easy component placement and documentation.
📦
Gerber Export
Download production-ready Gerber and Excellon drill files. Upload directly to JLCPCB, PCBWay, Aisler or any manufacturer.
👁️
Live Preview
See your board rendered in real-time as you adjust parameters. What you see is what gets manufactured.
Three steps to your custom perfboard
1
Configure
Set your board dimensions, choose pad grid density, enable power rails, mounting holes and silkscreen labels. The live preview updates with every change.
2
Preview & Adjust
Check the rendered board in the interactive preview. Verify pad placement, rail positions and hole keepout zones. Fine-tune until it's right.
3
Export & Order
Download the Gerber file package (copper layers, solder mask, silkscreen, drill file) and upload it to your preferred PCB manufacturer. Boards typically arrive within a week.
Made by an engineer, for makers.
ProtoGrid is built and maintained by Martin – electronics engineer and founder of MacGizmo.
